Grinder Pump
WQG Series
The WQG sewage cutting pump features a unique impeller design with cutting function. .
Характеристики

Extraordinary anti-clogging capability

Exchangeable blades for different applications

Different blade material available

Ideal for complicated sewage with soft solid matters

  • Описание
  • Параметры
  • Скачать
  • Вопросы и ответы
  • Сообщение

1. Product Overview

The WQG sewage cutting pump features a unique impeller design with cutting function. This configuration ensures high-efficiency hydraulic performance surpassing comparable products while delivering superior shredding capability, effectively fragmenting and discharging waste materials such as straw, cotton, cloth, and disposable diapers. Blades are made of materials with alloy with a Rockwell hardness of 48HR or above and are replaceable.

2. Application

 Discharge of highly polluted wastewater from industrial and commercial facilities;

 Residential area sewage disposal;

● Hospital and hotel sewage treatment;

● Water supply and drainage systems in urban sewage treatment plants;

● Drainage in civil air defense systems;

● Municipal engineering projects and construction sites;

● Rural biogas production and agricultural irrigation.

2. Key Features

 Extraordinary anti-clogging capability;

 Exchangeable blades for different applications

● Different blade material available

● Ideal for complicated sewage with soft solid matters.








Technical data

  • Rotating speed

    2900r/min

  • Voltage

    380V

  • Diameter

    DN50 DN65 DN80 DN100

  • Flow Range

    12-100m³/h

  • Lift Range

    10-20m

  • Power

    1.1-7.5kw

  • Frequency

    50HZ

  • Protection Level

    IP68

  • Insulation Class

    F

Materials

  • Pump body

    Cast iron

  • Impeller

    Cast iron

  • Shaft

    40Cr

  • Mechanical seal

    Impeller side: Silicon carbide/Silicon carbide/NBR

  • Mechanical seal

    Motor side: Carbon/Ceramic/NBR

  • How to achieve automatic control?

    • You can choose to be equipped with a float switch or a fully automatic control cabinet to automatically start and stop the pump, and monitor abnormalities such as water leakage and overload.
  • What are the motor protection measures?

    • It has functions of overheat protection and leakage monitoring.
