Symmetrical design enables bidirectional installation
Minimizes environmental nuisance from noise and vibration.
Reduced installation and initial project investment
Less installation space and simple operation.
1. Overview
The ZMB Gate Pump is designed for applications such as flood prevention and drainage, water diversion and drainage, and irrigation water distribution, including urban rainwater pump stations, flood control pump stations, agricultural irrigation pump stations, and drainage pump stations.
This pump excels in low-head, high-flow scenarios. Under identical head and specific speed conditions, it demonstrates higher overall efficiency compared to conventional vertical axial flow pumps and submerged vertical axial flow pumps. Specifically, the lower the head and the higher the specific speed, the greater the efficiency improvement.
It is suitable for conveying water or other liquids with physical and chemical properties similar to water, with a maximum liquid temperature of 40°C (104°F).
2. Application
● Flood Prevention and Drainage Systems
● Water Diversion and Distribution Projects
● Irrigation Water Supply Networks
● Urban Stormwater Pump Stations
● Flood Control Pump Stations
● Agricultural Irrigation Pump Stations
● General Drainage Infrastructure
3. Characteristics
● Compact structure with shortened axial dimensions, lightweight, and minimal metal consumption.
● Operates submerged, producing low noise and vibration, effectively reducing acoustic and thermal pollution.
● Short flow path with straight channel, minimizing head loss and achieving high system efficiency.
● Symmetrical design for flexible bidirectional installation, enabling reverse flow operation.
● Lightweight and compact, allowing quick self-coupling installation.
● Simplified pump station structure, reducing engineering workload, cost, and construction duration.
● Easy operation and maintenance, supporting automated control.
