Mixer LM-CJB
Wall-penetrating mixer is a new type of stirring device independently developed using submerged sealing technology. It is mainly used in large tanks, reactors, and other containers requiring mixing..
Характеристики

Gear-driven design with reducer eliminates structural vibration.

Multi-Layer Seal with leak-proof plug enables replacement without drainage.

Gear-driven design reduces mechanical failure risks, enhancing safety and reliability.

Quick-access seal design minimizes downtime and complexity.

  • Описание
  • Параметры
  • Скачать
  • Вопросы и ответы
  • Сообщение

1. Overview

The wall-penetrating mixer comprises transmission components, an impeller, a sealing chamber, etc. Its working principle involves using an external power source to rotate the impeller inside a sealed container through a transmission shaft, enabling solid-liquid-gas mixing to prevent solid settling.

2.Application

      ●  large tanks

      ●  reactors

      ●  Other containers requiring mixing

3.Characteristics

  This equipment employs a reducer and gear transmission system, ensuring smooth operation without affecting the mixing vessel or its structure.

  The power components and sealing elements are designed externally, facilitating maintenance without emptying the tank. Particularly suitable for high-temperature, highly corrosive, and high-concentration liquid environments.

  Equipped with multiple sealing layers and a leakage plugging device, it enables seal replacement without draining the tank, ensuring safer and more reliable operation while simplifying maintenance.



Technical data

  • Impeller diameter (mm)

    320-850

  • Rotation speed (rpm)

    35-385

  • Power (kw)

    3-10

  • Weight(kg)

    <350

  • Motor Insulation Class

    F

  • Motor Protection Class

    IP54

  • Voltage

    Three-phase (380-415)V±10%

  • Frequency (Hz)

    50Hz (optionally 60Hz)

Materials

  • Housing Material

    Cast lron/Stainless Steel

  • Blade Material

    Stainless Steel

  • How does a wall-penetrating mixer work, and what are its key advantages?

    • The mixer operates by using an external power source to rotate an impeller inside a sealed container via a transmission shaft. Its core advantages include non-disassembly maintenance (thanks to external power/sealing design), multi-stage sealing for leak prevention, and compatibility with high-temperature, highly corrosive, or high-concentration liquid environments.
  • Does the mixer require draining the tank for maintenance?

    • No. Its multi-seal system and leakage plugging device allow seal replacement without draining the tank, minimizing downtime and ensuring continuous operation in critical processes like chemical mixing or slurry handling.
